Airtac 2JW Angle Seat Valve 2JWK15010Q40G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JWK15010Q40G Angle Seat Valve Technical Details
- Model: 2JWK15010Q40G
- Type: 2/2-way normally closed (pneumatic actuation)
- Port size: G1/2" (DN15)
- Operating pressure: 0.15–1.0 MPa
- Voltage options: DC24V (±10%), AC110V/220V (±15%)
- Weight: ~650g (including coil)
- Dimensions: 80mm(L) × 40mm(W) × 90mm(H)
- Seal material: PTFE/Viton composite
- Temperature range: -10℃ to 180℃ (media), -20℃ to 60℃ (ambient)
- Flow coefficient (Cv): 4.2
- Response time: ≤50ms (actuation)
- Protection rating: IP67 (coil), IP65 (valve body)
- Housing material: Stainless steel CF8M (316 equivalent)
High-temperature angle seat valve with zero-leakage design, featuring a 45° flow path for optimized fluid dynamics. The stainless steel construction ensures corrosion resistance in aggressive media environments. Includes manual override and position indicator. Requires 5μm filtered air supply (max 50mg/m³ oil content).
- Steam line control in food processing systems
- High-pressure CIP (Clean-in-Place) systems
- Chemical dosing systems with corrosive media
- Thermal oil circulation control
- Pharmaceutical autoclave steam management
Installation guidelines:
Mount with flow direction arrow aligned. For steam applications,
install condensate separator upstream. Allow 15mm clearance
for thermal expansion. Torque mounting bolts to 25-30 N·m.
| Property | Property Value |
|---|---|
| sku | 2JWK15010Q40G |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
