Airtac 2JW Angle Seat Valve 2JWK15010Q50G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JWK15010Q50G Angle Seat Valve Specifications
- Model: 2JWK15010Q50G
- Type: 2-way normally open (pneumatic actuation)
- Port connection: G1/2" ISO228 standard
- Body material: Stainless steel CF8M (316 equivalent)
- Seal material: PTFE + FKM compound
- Operating pressure: 0.1–1.0 MPa
- Temperature range: -10℃ to +180℃
- Flow coefficient (Cv): 4.2
- Actuation pressure: 0.15–0.8 MPa
- Response time: ≤0.3s (open/close cycle)
- Weight: 0.82 kg ±5%
- Dimensions: 120mm(L) × 50mm(W) × 70mm(H)
- Protection rating: IP67 (submersible design)
- Certifications: RoHS, REACH, FDA-compliant seals
High-flow angle seat valve with 90° body orientation for steam/fluid control. Features snap-action piston mechanism with position indicator window. The stainless steel construction and triple-layered PTFE seals enable chemical resistance in aggressive media. Requires 5μm filtered air supply for actuator.
- Steam sterilization systems in pharmaceutical plants
- High-temperature CIP (Clean-in-Place) processes
- Beverage filling line shut-off control
- Chemical dosing systems with corrosive liquids
- Textile dyeing machine pressure regulation
Installation guidelines:
Mount with flow direction arrow aligned. For viscous fluids,
install in vertical pipe with actuator upward. Perform monthly
stem lubrication using silicone-free grease (ISO VG 32 equivalent).
| Property | Property Value |
|---|---|
| sku | 2JWK15010Q50G |
| Port Size | G3/8 |
| Flow Aperture | <15mm> |
