Airtac 2JW Angle Seat Valve 2JWK15015Q50G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JWK15015Q50G Angle Seat Valve Specifications
- Model: 2JWK15015Q50G
- Type: 2-way normally open (manual reset)
- Port size: G1/2" (BSPP thread)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: AC24V (±10%), AC110V (±10%), AC220V (±10%)
- Weight: 1.25 kg (2.76 lbs)
- Dimensions: 150mm(L) × 85mm(W) × 105mm(H)
- Seal material: PTFE + FKM (high-temperature resistant)
- Temperature range: -10℃ to 180℃ (14°F to 356°F)
- Flow rate: 1500 L/min (Cv value: 4.0)
- Response time: ≤0.1s (at 0.5 MPa)
- Protection rating: IP67 (dust/water resistant)
- Housing material: Stainless steel SS304
- Actuation type: Electropneumatic with manual override
Heavy-duty angle seat valve featuring 90° flow path optimization for steam and aggressive media control. The stainless steel body with triple-layer PTFE sealing ensures zero-leak performance in high-vibration environments. Includes thermal compensation design for stable operation during temperature fluctuations.
- Steam sterilization systems in pharmaceutical equipment
- High-temperature liquid dispensing in food processing
- Corrosive chemical transfer in semiconductor fabs
- Hydraulic line shut-off in plastic injection molding
- Brewery CIP (Clean-in-Place) systems
Installation note:
Must install with valve stem axis vertical (±5° tolerance).
Requires upstream 5μm filter and 0.5-1.0mm orifice upstream
for pressure stabilization. Lubricate seals with silicone grease
(Parker O-Lube 111 recommended) during annual maintenance.
| Property | Property Value |
|---|---|
| sku | 2JWK15015Q50G |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
