Airtac 2JW Angle Seat Valve 2JWK32032Q80G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JWK32032Q80G Angle Seat Valve Specifications
- Model: 2JWK32032Q80G
- Type: 2-position 3-way normally closed (mechanical spring return)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 480g ±5% (including coil)
- Dimensions: 82mm(L) × 45mm(W) × 75mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE backup rings
- Temperature range: -5℃ to 80℃ (fluid/ambient)
- Flow coefficient (Cv): 3.2 at 6 bar
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Protection rating: IP67 (coil), IP65 (valve body)
- Housing material: Die-cast aluminum alloy with chromate coating
- Actuation angle: 90° rotary motion
- Manual override: Optional screw-type override available
High-flow angle seat valve with stainless steel piston and ceramic shaft bearings, designed for aggressive media and high-cycle applications. Features zero-leakage poppet design with 5-million cycle durability rating. Compatible with steam (max 150℃ intermittent) when using high-temp seals (optional). Requires 5μm filtered air supply with lubrication prohibited.
- Sterilization systems in food processing lines
- Coolant control in CNC machining centers
- Batch process control in pharmaceutical equipment
- High-speed packaging machine actuators
- Chemical dosing systems with corrosive fluids
Installation guidelines:
Mount with actuator shaft horizontal to prevent debris accumulation.
Use vibration-resistant mounting brackets in high-shock environments.
Allow 20mm clearance for manual override operation. Pipe connections
must align without mechanical stress.
| Property | Property Value |
|---|---|
| sku | 2JWK32032Q80G |
| Port Size | G1-1/4 |
| Flow Aperture | <32 mm> |
