Airtac 2JW Angle Seat Valve 2JWY15015Q40G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JWY15015Q40G Angle Seat Valve Specifications
- Model: 2JWY15015Q40G
- Type: 2-way normally open (pneumatic actuation)
- Port connection: G1/2" (ISO228/1 standard)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max working pressure: 1.0 MPa (145 PSI)
- Temperature range: -5℃ to 80℃ (23℉ to 176℉)
- Valve body material: Stainless steel CF8M (SS316 equivalent)
- Seal material: NBR/FKM optional
- Actuator type: Piston cylinder with spring return
- Flow coefficient (Cv): 4.2
- Response time: ≤0.3s (at 0.6 MPa)
- Weight: 1.2 kg (2.65 lbs)
- Dimensions: 150mm(L) × 50mm(W) × 100mm(H)
- Protection rating: IP67 (dust/water resistant)
- Mounting orientation: Horizontal or vertical (port downward)
High-flow angle seat valve with 90° flow path design, optimized for viscous fluids and steam applications. Features stainless steel construction with electropolished internal surfaces (Ra≤0.8μm) for contamination resistance. Spring-assisted quick-closing mechanism ensures positive shut-off even during pressure drops.
- Food & beverage CIP/SIP systems
- Pharmaceutical liquid transfer lines
- Industrial steam control in sterilizers
- High-viscosity material handling (adhesives, resins)
- Cooling water circulation systems
Installation note:
Always install with flow direction arrow aligned. For steam applications,
allow 15-minute warm-up period with valve partially open to prevent thermal shock.
Lubricate actuator pivot points every 2,000 cycles using silicone-based grease.
| Property | Property Value |
|---|---|
| sku | 2JWY15015Q40G |
| Port Size | G1/2 |
| Flow Aperture | <15mm> |
