Airtac 2JW Angle Seat Valve 2JWY25025Q50G
2. Stainless steel construction of body and linkage rod ensures superior corrosion resistance. PTFE seals provide wide compatibility with high-temperature and highly corrosive fluids.
3. 45° angular seat design with streamlined internal cavity reduces flow path resistance for stabilized fluid flow and achieves high flow rates. Integrated filter element in linkage rod prevents contaminant ingress, extending service life.
4. Actuator equipped with visual position indicator window for real-time valve opening monitoring and flow regulation. Convertible to accommodate limit switches or emergency manual override.
5. Recessed metal fittings on actuator ports with transitional mounting plate ensures simplified integration with NAMUR solenoid valves.
6. 360° rotatable actuator design simplifies installation orientation.
Category: Angular Seat Valves | Brand: AirTAC | Series: 2JW
AirTAC 2JWY25025Q50G Angle Seat Valve Specifications
- Model: 2JWY25025Q50G
- Type: 2-way normally open (manual reset)
- Port size: G1" (BSPP thread)
- Valve diameter: DN25
- Operating pressure: 0.2–1.0 MPa
- Max working pressure: 10 bar
- Temperature range: -10℃ to 180℃ (with FKM seals)
- Seal material: Standard FKM (Fluorocarbon Rubber)
- Body material: Stainless steel CF8M (316 equivalent)
- Actuation type: Pneumatic control with spring return
- Control pressure: 0.15–0.8 MPa
- Flow coefficient (Cv): 16.5
- Weight: 2.8 kg ±3%
- Dimensions: 160mm(L) × 105mm(W) × 225mm(H)
- Protection rating: IP67 (with optional cover)
- Response time: ≤0.3s (at 0.6 MPa)
Heavy-duty angle seat valve with 90° flow path design, optimized for high-temperature liquid and steam applications. Features forged stainless steel body with electropolished internals for reduced particle contamination. The "Q50G" variant includes a thermal insulation sleeve for steam lines above 150℃.
- Steam sterilization systems in pharmaceutical manufacturing
- High-pressure CIP (Clean-in-Place) systems in dairy processing
- Thermal oil circulation control
- Brewery pasteurization line control
- Chemical dosing systems with aggressive media
Installation note:
Must be installed with flow direction arrow aligned. For steam applications,
allow 20-minute warm-up period with valve partially open to prevent thermal shock.
Use PTFE thread sealant instead of tape for G-port connections.
| Property | Property Value |
|---|---|
| sku | 2JWY25025Q50G |
| Port Size | G1 |
| Flow Aperture | <25 mm> |
