Airtac 5A Pneumatic Control Valve 5A330P08
2. 3-position pneumatic valve offers three center position functions (exhaust blocked, pressure retained, or exhaust center);
3. 2-position double pilot-operated valve features memory function to retain the last control state;
4. Precision-machined internal bore reduces friction resistance, enabling low actuation pressure and extended service life;
5. Oil-free lubrication design eliminates the need for external lubrication;
6. Modular design allows integration with manifold bases to save installation space;
**Category**: Pneumatic Control Valves | **Brand**: AirTAC | **Series**: 5A --- Note: The translation incorporates industry-specific terminology (e.g., "spool-type," "double pilot-operated," "manifold bases") and structural clarity while retaining the original HTML line breaks. Key technical features like memory function, modularity, and lubrication-free operation are emphasized for professional context.
AirTAC 5A330P08 Pneumatic Control Valve Specifications
- Model: 5A330P08
- Type: 5/3-way (3-position, 5-port) closed center
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–0.8 MPa (29–116 PSI)
- Actuation: Double solenoid pilot-operated
- Voltage options: DC12V, DC24V, AC110V 50/60Hz, AC220V 50/60Hz
- Weight: 650g ±5% (with solenoids)
- Dimensions: 55mm(L) × 40mm(W) × 90mm(H)
- Flow capacity: 1200 Nl/min (Cv=1.8)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (no ice formation)
- Power consumption: 2.2W (DC), 4.5VA (AC)
- Response time: ≤30ms (at rated voltage)
- Protection rating: IP67 (solenoid), IP40 (valve body)
- Port thread depth: 12mm (minimum engagement)
High-flow directional control valve with center-block function, featuring dual redundant manual overrides and LED status indicators. The hardened aluminum body with chromed brass core ensures 5 million cycle durability. Designed for bi-directional cylinder control requiring mid-position pressure locking.
- Automated production line cylinder sequencing
- Plastic injection molding machine clamp control
- Material handling system safety interlocks
- Automotive tire assembly equipment
- Die-casting machine hydraulic-pneumatic interfaces
Installation note:
Mount horizontally with actuator shafts parallel to ground. Use 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 quality. Apply thread sealant only on male ports, avoiding contamination of spool chamber.
| Property | Property Value |
|---|---|
| sku | 5A330P08 |
| Position | 5-port 3-position |
| Port Size | PT1/4 |
