Airtac B52-GZ Non-Copper Shut-Off Valve B52-GZ40015
AirTAC B52-GZ Copper-Free Shutoff Valve B52-GZ40015 Technical Details
- Model: B52-GZ40015
- Type: 2-way normally closed manual shutoff valve (copper-free)
- Port size: G1/4 (ISO228 standard)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Max flow capacity: 650 L/min (Cv=0.36)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: Fluorocarbon rubber (FKM)
- Body material: Anodized aluminum alloy (copper-free design)
- Operation: Manual lever actuation (90° rotation)
- Weight: 320g ±5g
- Dimensions: 45mm(L) × 32mm(W) × 65mm(H)
- Port thread depth: 12mm engagement length
- Leakage rate: ≤3 bubbles/min (ISO 6952 standard)
- Protection rating: IP40 (non-dustproof)
Industrial-grade isolation valve specifically engineered for copper-sensitive environments. Features corrosion-resistant anodized finish and chemical-resistant FKM seals. The 90° quarter-turn operation enables rapid system isolation with tactile feedback. Includes integrated position indicator window for visual flow confirmation.
- Refrigeration systems (ammonia-based cooling circuits)
- Chemical processing equipment (acid/alkali media transfer)
- Semiconductor manufacturing gas lines
- Marine hydraulic systems (saltwater exposure environments)
- Pharmaceutical pure steam distribution
Installation guidelines:
Install with flow direction arrow aligned to media flow. Apply thread sealant only on male threads (PTFE tape recommended).
For horizontal piping, orient lever upward for closed position indication. Perform monthly lubrication of rotating mechanism using silicone-based grease.
