Airtac CPV15-E-F-R-C-B-A Miniature Solenoid Valve CPV15F
2. Low activation voltage ensures extended service life.
3. Hum-free operation with AC power supply eliminates buzzing noise issues.
4. Integrated surge suppression protects the solenoid valve from voltage spike damage.
Category: Miniature Solenoid Valves | Brand: AIRTAC | Series: CPV15-E-F-R-C-B-A
AirTAC CPV15-E-F-R-C-B-A Micro Solenoid Valve (CPV15F Series) Specifications
- Full model code: CPV15-E-F-R-C-B-A
- Valve type: 5/2-way monostable (spring return)
- Port configuration: M5 thread (ISO 228 G1/8 optional)
- Operating pressure range: 0.05–0.7 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Effective sectional area: 1.8mm² (Cv=0.008)
- Weight: 210g ±5g (including connector)
- Dimensions: 54mm(L) × 35mm(W) × 36mm(H) (excluding fittings)
- Seal materials: FKM fluorocarbon (standard), optional EPDM for chemical resistance
- Ambient temperature: -10℃ to 60℃ (with no condensation)
- Power consumption: 1.6W (DC), 2.2VA (AC)
- Response time: ≤15ms (exhaust to operation)
- Protection class: IP67 (dustproof & waterproof)
- Port alignment: ISO 5599-1 standard
Ultra-compact 5-port pneumatic valve with manual override, designed for precision pneumatic circuits requiring multi-position control. Features gold-plated terminals for reliable conductivity and stainless steel plunger for 10 million cycle durability. Optimized for low power consumption and high-frequency switching (max 10Hz). Requires 5μm filtration with oil mist lubrication (ISO VG32 recommended).
- Medical device pneumatic actuators (dental chairs, analyzers)
- Semiconductor wafer handling robots
- Precision dispensing systems in SMT machines
- Compact automation cells in watch manufacturing
- Laboratory climate chamber controls
Installation notes:
Maintain ≥20mm clearance around valve body for heat dissipation.
Use flexible tubing to prevent stress on ports.
For vertical mounting, position coil section upward to prevent debris accumulation.
Requires surge protection circuit for DC models.
| Property | Property Value |
|---|---|
| sku | CPV15F |
| Standard Voltage | DC12V |
| Valve Body Width | <15mm> |
