Airtac GV Slow Start Valve GV20006NE
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Slow Start Valve GV20006NE Technical Details
- Model: GV20006NE
- Type: 3/2-way normally closed with slow-start function
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–0.9 MPa
- Response time: 0.3–5 sec (adjustable slow start)
- Voltage options: DC24V (±10%), AC110V/220V (±15%)
- Power consumption: 1.6W (DC), 2.2VA (AC)
- Weight: 280g ±5%
- Dimensions: 58mm(L) × 40mm(W) × 70mm(H)
- Flow capacity: 700 NL/min (ANR)
- Seal material: FKM (Viton) standard, EPDM optional
- Temperature range: -10℃ to 80℃ (extended to 120℃ with FKM seals)
- Protection rating: IP67 (dustproof & waterproof)
- Port thread depth: 12mm (minimum engagement)
- Hysteresis: ≤10% of rated voltage
Precision slow-start solenoid valve featuring progressive airflow control with adjustable ramp-up time (0.3-5 seconds). The hardened aluminum body with electroless nickel plating provides corrosion resistance in humid environments. Integrated surge protection and LED status indicator. Requires 5μm filtered dry air with oil mist ≤1mg/m³.
- Pneumatic cylinder soft-start systems
- Medical bed articulation mechanisms
- Packaging line product positioning
- Automated assembly torque control
- Cleanroom automation equipment
- Food processing machinery (FDA-compliant versions available)
Installation guidelines:1. Mount in vibration-free locations using M4 mounting screws
2. Maintain ≥15mm clearance on exhaust port side
3. Use flexible tubing for pressure fluctuations >0.3 MPa
4. Perform monthly manual cycling during standby periods
| Property | Property Value |
|---|---|
| sku | GV20006NE |
| Pressure Gauge Code | Without attached table |
| Port Size | PT1/8 |
| Bracket Code | With Bracket |
| Coil Voltage | AC24V |
