Airtac GV Slow Start Valve GV20008JNB
Category: Slow Start Valves | Brand: AirTAC | Series: GV
AirTAC GV Slow Start Valve GV20008JNB Technical Details
- Full model designation: GV20008JNB (JN=slow start variant, B=body material code)
- Valve type: 3/2-way normally closed with delayed activation
- Port configuration: G1/8 (ISO228-1 compliant) with 4.5mm orifice diameter
- Pressure range: 0.15–1.0 MPa (21.7–145 PSI)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Coil insulation class: Class F (155°C)
- Flow capacity: 750 NL/min (ANR, at 0.5MPa)
- Response time: 30-120ms adjustable (via integrated needle valve)
- Weight: 298g ±5g (including coil and accessories)
- Body dimensions: 54mm(W) × 55mm(H) × 74mm(D)
- Seal materials: HNBR main seals, FKM secondary seals (-20℃ to 150℃)
- Operating temperature: -5℃ to 80℃ (non-freezing environment)
- Protection standard: IP67 (dust/water resistant) with epoxy-coated coil
- Manual override: Built-in push button with lockable function
- Mounting orientation: Any (horizontal/vertical)
Precision slow-start pneumatic valve engineered for controlled actuator acceleration. Features anti-water-hammer design with progressive pressure buildup (0.1-3 sec adjustable). Nickel-plated brass body with stainless steel core components ensures corrosion resistance in humid environments. Includes LED status indicator and surge protection circuitry.
- Precision assembly robots requiring smooth motion profiles
- Elevator door control systems for gradual opening/closing
- Injection molding machine ejector sequencing
- Food processing pneumatic actuators needing splash resistance
- Semiconductor handling equipment with vibration-sensitive operations
Installation protocol:
Install downstream of 5μm filter regulator. For optimal performance,
maintain 0.3m/sec maximum air velocity in connected piping.
Lubrication not required (maintenance-free design). Replace desiccant
every 2,000 operating hours in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | GV20008JNB |
| Pressure Gauge Code | Without attached table |
| Port Size | PT1/4 |
| Bracket Code | Without bracket |
| Coil Voltage | DC24V |
