Airtac MCK Welding Clamping Cylinder MCK80X125SE
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X125SE Welding Clamping Cylinder Specifications
- Model: MCK80X125SE
- Type: Double-acting welded clamping cylinder
- Bore size: 80 mm
- Stroke: 125 mm
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Buffer type: Adjustable cushioning (both ends)
- Seal material: Heat-resistant NBR (Nitrile rubber)
- Port size: G3/8 (ISO standard thread)
- Mounting type: Fixed base with reinforced mounting holes
- Piston rod material: Chrome-plated steel (Cr-Mo alloy)
- Weight: 5.2 kg ±3% (without accessories)
- Dimensions: 340mm(L) × 112mm(W) × 112mm(H) (at fully retracted position)
- Rod thread: M20×1.5 (external)
- Protection rating: IP54 (standard dust/moisture resistance)
Heavy-duty welding clamp cylinder engineered for robust performance in high-temperature industrial environments. Features a reinforced body structure with anti-spatter coating (2-5μm thickness) to withstand welding debris. The dual-piston design ensures 2,500N maximum clamping force at 0.6 MPa, with ±0.5mm repeat positioning accuracy.
- Robotic welding fixture systems
- Automotive chassis component assembly
- Metal fabrication jigs
- Forging machine tool positioning
- Battery pack welding stations (EV manufacturing)
Operational guidance:
Maintain air supply dew point -15℃ below ambient temperature. Use ISO VG32 hydraulic oil
for lubrication (1 drop/m³ airflow recommended). For welding applications, install
protective boot (sold separately) to prevent spatter accumulation. Alignment tolerance:
≤0.2mm/meter during installation.
| Property | Property Value |
|---|---|
| sku | MCK80X125SE |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 125mm |
