Airtac MCK Welding Clamping Cylinder MCK80X50-E
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK Welding Clamping Cylinder MCK80X50-E Technical Details
- Model: MCK80X50-E
- Bore size: Ø80mm
- Stroke: 50mm (Standard)
- Operating pressure: 0.1–0.8 MPa
- Mounting type: Fixed flange (ISO 15552 standard)
- Cushioning: Adjustable air cushion + shock absorber
- Ambient temperature: -20℃ to 80℃
- Piston material: High-grade aluminum alloy (hard anodized)
- Rod material: Chrome-plated stainless steel (SUS304)
- Seal type: NBR + PU hybrid seals
- Weight: 4.8kg ±2%
- Dimensions (L×W×H): 300mm × 80mm × 80mm (excluding mounting accessories)
- Port thread: G3/8 (BSPP)
- Max thrust: 4020N @0.6MPa
- Repeat positioning accuracy: ±0.5mm
- ISO certification: 6431/DIN ISO 15552 compliant
Heavy-duty welding clamp cylinder with thermal-resistant construction, featuring double piston guides for anti-rotation stability. Integrated magnetic slot allows position feedback sensor installation (sensor not included). The hardened piston rod surface (HRC 45-50) resists spatter damage in welding environments.
- Robotic welding fixture systems
- Automotive chassis component clamping
- High-temperature metal stamping press tooling
- Forging machine workpiece positioning
- Battery module assembly jigs
Installation protocol:
Use heat-resistant grease (≥200℃ rating) on rod surface before operation.
Maintain 0.3-0.5mm clearance between clamp jaws and cylinder body during welding processes.
Requires 5μm filtration with water separator for optimal performance.
| Property | Property Value |
|---|---|
| sku | MCK80X50-E |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <50mm> |
