Airtac MCK Welding Clamping Cylinder MCK80X75-E
$107.23
Regular price
$114.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MCK80X75-E
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Product Description:**
1. Engineered for automotive welding workshop environments, offering superior resistance to high temperatures and contamination;
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
Installation note:
Apply anti-spatter compound (JIS Z3284 Type 2 recommended) on rod surface before commissioning.
Maintain 0.5-1mm clearance between clamp arm and cylinder body for thermal expansion.
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X75-E Welding Clamping Cylinder Specifications
- Model: MCK80X75-E
- Type: Compact welded clamping cylinder (double-acting)
- Bore size: Ø80 mm
- Stroke: 75 mm
- Operating pressure: 0.1–1.0 MPa
- Piston rod material: Hard chrome-plated steel (Cr-Mo)
- Cylinder tube: Anodized aluminum alloy
- Cushioning: Adjustable rubber buffer
- Mounting style: Front flange/Foot mounting (optional accessories)
- Ambient temperature: -20℃ to 150℃ (high-temp seals optional)
- Weight: 9.8 kg ±2%
- Dimensions:
- Extended length: 272 mm
- Retracted length: 197 mm
- Body width: 115 mm
- Mounting base height: 25 mm
- Port size: G3/8 (BSPP thread)
- Seal material: High-temperature NBR (standard)/FKM (optional)
- Protection rating: IP54 (standard)/IP67 (with wiper upgrade)
Heavy-duty welding cylinder engineered for robotic welding stations and high-vibration environments. Features enhanced heat-resistant construction with nickel-plated end caps and reinforced mounting lugs. The E-series upgrade includes tungsten-carbide scraper rings for slag protection in welding applications.
Typical Applications:
- Automotive chassis welding fixtures
- Battery pack assembly clamping
- Foundry mold holding systems
- CNC machining center workpiece fixation
- High-temperature composite material pressing
Installation note:
Apply anti-spatter compound (JIS Z3284 Type 2 recommended) on rod surface before commissioning.
Maintain 0.5-1mm clearance between clamp arm and cylinder body for thermal expansion.
Special Features:
- Integrated heat shield sleeve (replaceable)
- Magnetic sensor grooves (M9x1 pre-tapped)
- Double-lip rod wiper for spark debris exclusion
- Asymmetric cushioning (30% stronger on extension stroke)
| Property | Property Value |
|---|---|
| sku | MCK80X75-E |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 75mm |
