Airtac PM Panel Mount Straight Coupling PM30
AirTAC PM Series Bulkhead Straight Through Connector PM30 Specifications
- Model: PM30
- Type: Metric thread through-bulkhead connector
- Port size: M5×0.8 dual-end thread
- Material: Aluminum alloy (A6061-T6 anodized)
- Max working pressure: 1.0 MPa
- Proof pressure: 1.5 MPa
- Burst pressure: 3.0 MPa
- Temperature range: -20℃ to 80℃
- Weight: 18g ±0.5g
- Dimensions: 30mm (Total length) × 12mm (Hex size) × 8mm (Thread engagement length)
- Seal material: NBR (Standard) / Optional FKM
- Surface treatment: Clear anodization (RAL 9006)
- Installation thickness: Compatible with panels 1-5mm thick
- Vibration resistance: 10-2000Hz, 15G acceleration
- Corrosion resistance: 96hrs salt spray test passed
High-density pneumatic interface designed for panel-mounted installations in confined spaces. Features dual O-ring sealing (front and back) with anti-rotation hex design for tool-free adjustment. The tapered thread design prevents hydraulic lock during installation. Compatible with ISO 15407-1 standard pneumatic systems.
- Modular pneumatic control cabinets
- Robotic arm junction interfaces
- CNC machine tool manifold blocks
- Semiconductor equipment panels
- Mobile hydraulic power units
- Laboratory instrument air distribution
Installation protocol:
Apply 0.3-0.5Nm torque during installation. Use thread sealant only on male threads.
For thin panels (<2mm), use backup washers to prevent deformation. Perform pressure
test at 1.25× working pressure after installation.
- Cv value: 0.15
- Effective area: 1.8 mm²
- Flow rate @0.5MPa: 120 NL/min
- Pressure drop curve: 0.02MPa @50 NL/min flow
| Property | Property Value |
|---|---|
| sku | PM30 |
