Airtac SGD Series Steel Tube Type Double Rod Cylinder SGD125X400FA
2. SG Series features dual Y-type single-acting piston seals with automatic compensation, ensuring extended service life and low starting pressure. SGC Series adopts profiled dual-acting seal configuration for compact design and integrated oil reservoir capability;
3. SG Series utilizes cold drawn steel tubing construction with superior impact resistance;
4. SGC Series employs precision aluminum tubing with optional embedded sensor magnets (not compatible with SG Series);
5. Equipped with adjustable pneumatic cushioning mechanism for smooth deceleration control;
6. Comprehensive size range with multiple mounting accessories for flexible system integration;
7. Engineered with high humidity-resistant sealing compounds for operational temperature range of 0-150°C.
Category: Twin Shaft Cylinders | Brand: AIRTAC | Series: SGD
AirTAC SGD Series Steel Tube Double Rod Cylinder SGD125X400FA Specifications
- Model: SGD125X400FA
- Bore size: 125mm (ISO 6432 standard)
- Stroke: 400mm (customizable 25-2000mm)
- Operating pressure: 0.05-1.0 MPa
- Rod type: Dual chrome-plated steel rods (hardness HRC 45-55)
- Mounting style: Basic type (optional MF/MP mounts)
- Cushioning: Adjustable pneumatic cushion
- Temperature range: -20℃ to 80℃
- Port size: G1/2 (BSPP thread)
- Piston rod thread: M20×1.5 (double rod synchronized)
- Weight: 24.5kg ±2% (without accessories)
- Dimensions: 695mm(L) × 158mm(W) × 158mm(H)
- Seal material: NBR (nitrile rubber)
- Tube material: Cold drawn precision steel tube
- ISO standard: 6431/15552 compliant
Industrial-grade double rod cylinder featuring symmetrical force distribution and enhanced moment resistance. The steel tube construction ensures superior durability for heavy-load applications. Dual rod design minimizes rotational deflection during operation, with IP65 protection against particulate ingress.
- Press machine clamping mechanisms
- Automated palletizing systems
- Foundry equipment actuation
- Plastic injection molding ejectors
- Automotive welding fixture positioning
Installation note:
Ensure parallel alignment of dual rods using precision guides. Lubricate rod bearings with ISO VG32 hydraulic oil.
Maximum side load capacity: 850N at mid-stroke. Allow 15mm clearance for thermal expansion.
| Property | Property Value |
|---|---|
| sku | SGD125X400FA |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Cushion Stroke | <40mm> |
| Bore Diameter | 125mm |
| Stroke | <400mm> |
