Airtac SILF Front Locking Air Cylinder SIF40X75
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Series Front Lock Cylinder SIF40X75 Technical Details
- Model: SIF40X75
- Bore size: 40mm
- Stroke: 75mm
- Operation type: Double-acting with mechanical lock
- Locking mechanism: Spring-activated wedge system
- Working pressure: 0.1–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/2 (NPT1/2 optional)
- Rod thread: M20×1.5
- Material: Aluminum alloy barrel, hardened chromium piston rod
- Seal type: NBR seals with wear-resistant guide rings
- Weight: 2.8kg (with standard accessories)
- Dimensions: 280mm(L) × 56mm(W) × 56mm(H) (retracted position)
- Extended length: 355mm (75mm stroke)
- Lock holding force: 1,200N max
- Response time: ≤0.5s (lock engagement)
Precision lock cylinder featuring fail-safe position retention during air supply interruptions. The wedge-type locking mechanism provides zero-backlash holding, ideal for vertical applications requiring emergency stop position maintenance. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 4) with recommended ISO VG32 hydraulic oil mist lubrication.
- Automated welding fixture position locking
- Elevator emergency brake systems
- CNC machine tool clamping mechanisms
- Material handling vertical lift safety stops
- Printing press roller engagement systems
Installation guidelines:
Maintain 0.5-1mm clearance between lock mechanism and mating surface.
Lubricate lock slider monthly with lithium soap grease.
Avoid side-load exceeding 30N during lock engagement.
| Property | Property Value |
|---|---|
| sku | SIF40X75 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 75mm |
| Lock Position | Front Cover with Lock |
