Airtac SILF Front Locking Air Cylinder SIF40X800
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Series Front Mechanical Lock Cylinder SIF40X800 Specifications
- Model: SIF40X800
- Type: Double-acting cylinder with front mechanical lock
- Bore size: 40mm
- Stroke: 800mm
- Operating pressure: 0.05–1.0 MPa
- Locking mechanism: Spring-loaded mechanical brake (front side)
- Port size: Rc1/4 (G1/4 optional)
- Cushioning type: Adjustable rubber buffer (both ends)
- Temperature range: -20℃ to 80℃
- Rod material: Chrome-plated steel
- Cylinder tube: Hard anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 3.85kg (excluding mounting accessories)
- Dimensions: 990mm(L) × 50mm(W) × 50mm(H) (full extension)
- Locking force: 480N (at 0.5MPa)
- Response time: ≤0.5s (locking engagement)
- Protection rating: IP54
Heavy-duty locking cylinder with fail-safe mechanical brake system, engineered for vertical load holding and position retention during power loss. Features dual-stage sealing with wear compensation and anti-rotation guide mechanism. Requires ISO 8573-1:2010 Class 3-4-3 compressed air quality.
- Vertical lifting systems in automated warehouses
- Press machine safety position locking
- Automotive assembly line fixture positioning
- Overhead material handling emergency brakes
- Plastic injection molding clamp retention
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3-0.6MPa locking pressure during adjustment.
Avoid side load exceeding 30N during locking engagement.
| Property | Property Value |
|---|---|
| sku | SIF40X800 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | 800mm |
| Lock Position | Front Cover with Lock |
