Airtac SILF Front Locking Air Cylinder SIF40X900
2. Unlocking methods: Featuring automatic and manual unlocking operation modes.
Category: Locking Cylinders , Brand: AIRTAC , Series: SILF
AirTAC SILF Front Lock Cylinder SIF40X900 Technical Details
- Model: SILF SIF40X900
- Bore size: 40mm
- Stroke: 900mm
- Operating pressure: 0.1–1.0 MPa
- Locking mechanism: Spring-loaded mechanical brake (front side)
- Mounting style: Standard foot/base mount (ISO 15552 compatible)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Cushioning: Adjustable air cushion (both ends)
- Piston rod material: Hard chrome-plated steel
- Cylinder tube: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 5.8kg (excluding accessories)
- Dimensions (L×W×H):
- Basic cylinder length: 282mm
- Full extended length: 282mm + 900mm stroke
- Width (mounting base): 64mm
- Height (including rod): 53mm
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (non-replenishing design)
High-precision locking cylinder with fail-safe position retention capability. Features dual-action braking system that activates automatically during power/pneumatic failure, preventing unintended movement. The reinforced rod design withstands lateral forces up to 150N, making it ideal for vertical load applications. Includes wear-resistant guide bushings for extended service life.
- Overhead load locking in automated assembly lines
- Emergency stop position retention in CNC tool changers
- Vertical press machinery safety brakes
- Material handling elevator position locks
- Solar panel tilt adjustment mechanisms
Installation guidelines:
Maintain ≤0.5mm alignment tolerance during mounting. For vertical installations,
use auxiliary rod supports when handling loads exceeding 20kg.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil in high-cycle applications (＞500 cycles/day).
| Property | Property Value |
|---|---|
| sku | SIF40X900 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <900mm> |
| Lock Position | Front Cover with Lock |
