Airtac SULB Lock Cylinder SULB50X150
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB50X150 Locking Cylinder Specifications
- Model: SULB50X150
- Type: Double-acting rear lock cylinder
- Bore size: Ø50 mm
- Stroke: 150 mm (±0.5 mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Locking force: 1,470 N (at 0.5 MPa)
- Locking method: Spring-assisted mechanical brake
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: Rc1/4 (G1/4 optional)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + Polyurethane
- Ambient temperature: -20℃ to +80℃
- Weight: 2.65 kg (without accessories)
- Dimensions: 250mm(L) × 80mm(W) × 80mm(H) (minimum retracted length)
- Rod thread: M16×1.5 (external)
- Protection rating: IP54 (standard seals)
Heavy-duty locking cylinder with fail-safe position retention, featuring dual-stage mechanical locking mechanism activated by spring force and deactivated by air pressure (0.15 MPa minimum). Precision ground rod prevents rotational slippage during locking. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Vertical lifting mechanisms requiring position hold (e.g., elevator safety brakes)
- Press machine tooling position retention during power failure
- Automated assembly line fixture clamping
- Material handling systems with intermediate stop positions
- Robotic welding positioner axis locking
Installation guidelines:
Mount using M8×1.25 mounting bolts (ISO 4762) with 25 N·m torque.
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.5mm minimum clearance between lock mechanism and mating surface.
Critical note:
Lock engagement requires complete pressure release (≤0.02 MPa residual pressure).
Do not exceed 1,200mm/s piston speed during unlocking phase.
| Property | Property Value |
|---|---|
| sku | SULB50X150 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 150mm |
| Lock Position | Rear Cover with Lock Type |
