Airtac SULB Lock Cylinder SULB50X1500
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB50X1500 Locking Cylinder Technical Details
- Model: SULB50X1500
- Bore size: Ø50 mm
- Stroke: 1500 mm
- Operating pressure: 0.1–0.8 MPa
- Locking mechanism: Mechanical wedge-type brake (spring applied/pressure released)
- Action type: Double acting
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Front flange (MF1), rear foot (MP2), or center trunnion (MT4)
- Port size: G1/2 (ISO228/1 standard)
- Ambient temperature: -10℃ to +70℃
- Seal material: NBR (Nitrile) with wear-resistant guide rings
- Rod material: Hard chrome-plated carbon steel
- Protection rating: IP54 (standard), IP67 optional
- Weight: 15.2 kg ±5% (excluding accessories)
- Dimensions: 1550mm(L) × 80mm(W) × 80mm(H) (extended length)
Heavy-duty locking cylinder engineered for vertical load holding and emergency stop applications. Features dual-stage sealing with dust wiper and integrated brake monitoring ports. The reinforced rod design withstands side loads up to 15% of maximum thrust capacity. Requires ISO VG32 hydraulic oil lubrication for optimal brake performance.
- Automated assembly line position locking
- Elevator safety brakes in manufacturing facilities
- Overhead crane load suspension systems
- Press machine slide unit stabilization
- Solar panel tilt adjustment mechanisms
Installation guidelines:
Maintain 0.5-1mm clearance between brake unit and mounting surface.
Perform brake engagement test at 0.3 MPa before full operation.
Lubricate every 5,000 cycles or 3 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | SULB50X1500 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1500mm> |
| Lock Position | Rear Cover with Lock Type |
