Airtac SULB Lock Cylinder SULB63X125-S
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB63X125-S Locking Cylinder Technical Details
- Model: SULB63X125-S
- Type: Double-acting with mechanical lock
- Bore size: 63mm (ISO 6432 standard)
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Locking force: 1960N max @0.63MPa
- Cushioning: Adjustable pneumatic cushion
- Mounting type: Standard AF/FF flange (ISO 15552)
- Rod thread: M20×1.5 external thread
- Ambient temperature: -20℃ to +80℃
- Seal material: HNBR (hydrogenated nitrile)
- Port size: G1/8 (BSPP thread)
- Weight: 3.5kg (without accessories)
- Dimensions: 300mm(L) × 63mm(W) × 63mm(H)
- Rod end type: Female clevis with pin
- Repeat positioning accuracy: ±0.2mm
- Lock release pressure: ≥0.15MPa
Heavy-duty locking cylinder with integrated mechanical brake system, designed for vertical load holding and emergency stop scenarios. Features dual-position locking capability (mid-stroke and end positions) with manual override option. The chrome-plated piston rod and corrosion-resistant aluminum barrel ensure durability in harsh environments.
- Material handling equipment position locks
- Press machine safety interlocks
- Automated assembly line jig positioning
- Elevator emergency braking systems
- Solar panel tilt adjustment mechanisms
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Locking mechanism engages automatically at power failure - always install manual release lever
for maintenance access. Maintain 50mm clearance behind cylinder for rod extension.
- Magnetic sensor kit (D-M9NW)
- Heat-resistant seals (+120℃ version)
- Rod end adapters (ISO 23480-B)
- Anti-rotation guide modules
| Property | Property Value |
|---|---|
| sku | SULB63X125-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 125mm |
| Lock Position | Rear Cover with Lock Type |
