Airtac SULB Lock Cylinder SULB63X300
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB63X300 Locking Cylinder Specifications
- Model: SULB63X300
- Type: Double-acting cylinder with mechanical lock
- Bore size: 63 mm
- Stroke: 300 mm (±0.5 mm tolerance)
- Operating pressure: 0.1–1.0 MPa
- Locking force: 1,250 N (at 0.5 MPa)
- Lock release pressure: ≥0.15 MPa
- Cushioning: Adjustable rubber buffer
- Port size: G1/4 (NPT1/4 optional)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr12MoV)
- Seal type: NBR + PU combination seals
- Temperature range: -20℃ to 80℃
- Weight: 3.8 kg (without accessories)
- Dimensions:
- Extended length: 583 mm
- Retracted length: 283 mm
- Body diameter: 80 mm
- Mounting base: 125×125 mm
- ISO standard: 15552 (VDMA 24562)
- Protection rating: IP67 (rod side)
Heavy-duty locking cylinder featuring dual safety mechanisms - pneumatic holding and mechanical braking. The integrated wedge-lock system maintains position even during sudden pressure drops. Optimized for high side-load applications with hardened guide rings and wear-resistant rod coating. Requires 5-40 μm filtered air with ISO VG32 lubricant.
- Vertical load holding in material handling systems
- Emergency stop positioning in automotive assembly
- Precision fixturing for CNC machining centers
- Overhead safety brakes in elevator systems
- Position retention in earthquake-prone facilities
Installation note:
Locking mechanism requires manual release via M6×1 emergency screw during maintenance.
Maintain 0.5 mm minimum clearance between rod end and mechanical stops. Lubricate lock slots every 5,000 cycles.
| Property | Property Value |
|---|---|
| sku | SULB63X300 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 300mm |
| Lock Position | Rear Cover with Lock Type |
