Airtac SULB Lock Cylinder SULB63X450
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB63X450 Locking Cylinder Specifications
- Model: SULB63X450
- Type: Double-acting cylinder with mechanical lock
- Bore size: 63mm (ISO standard)
- Stroke: 450mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Locking force: 1,200N (at 0.5MPa)
- Lock type: Wedge mechanism with spring assist
- Cushioning: Adjustable pneumatic cushion
- Mounting: ISO 15552 standard flange (MF1/MF2 optional)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 5.8kg (without accessories)
- Dimensions: 738mm(L) × 80mm(W) × 80mm(H) (fully extended)
- Port size: G1/8 (M5 adaptor available)
- Protection rating: IP67 (wipers included)
Heavy-duty locking cylinder featuring fail-safe position retention through mechanical wedge locking. The dual-piston design ensures stable mid-stroke locking capability even during power/pressure loss. Integrated shock absorption reduces end-impact noise to <75dB. Requires ISO VG32 hydraulic oil lubrication for optimal seal performance.
- Vertical load braking in elevator safety systems
- Position holding in CNC rotary index tables
- Emergency stop mechanisms for press machines
- Overhead conveyor pause control
- Robotic welding fixture positioning
Installation note:
Lock engagement requires minimum 0.3MPa pressure. Allow 2-3mm free play in mounting brackets
to prevent side load. Perform lock release test every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | SULB63X450 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 450mm |
| Lock Position | Rear Cover with Lock Type |
