Airtac SULB Lock Cylinder SULB63X550
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB63X550 Locking Cylinder Specifications
- Model: SULB63X550
- Type: Double-acting with magnetic piston & mechanical lock
- Bore size: 63 mm
- Stroke: 550 mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: ≥1,500 N (at 0.5 MPa)
- Locking method: Mechanical wedge lock mechanism
- Operation direction: Bidirectional locking
- Cushioning: Adjustable pneumatic cushioning (both ends)
- Seal material: Polyurethane (PU) with wear-resistant ring
- Temperature range: -10℃ to 80℃
- Port size: PT1/2 (NPT1/2 optional)
- Mounting type: Standard ISO 15552 front flange (MF1), rear foot mounting (MP4 optional)
- Weight: 5.8 kg ±3% (excluding accessories)
- Dimensions: 735mm(L) × 80mm(W) × 80mm(H) (full extension)
- Rod thread: M16×1.5 external thread
- Repeat positioning accuracy: ±0.2 mm
Industrial-grade locking cylinder featuring fail-safe mechanical position retention. The dual magnetic sensing (D-M9B sensors compatible) and wedge-lock mechanism ensures zero drift during power/pneumatic failure. Hard chrome-plated piston rod with integrated scraper ring prevents contamination. Requires 5-50 μm filtered lubricated air (ISO 8573-1 Class 3).
- Vertical load holding in automated assembly lines
- Safety positioning in material handling systems
- Process interruption recovery in automotive welding jigs
- Intermediate stop control in injection molding machines
- Precision fixturing for CNC machining centers
Installation requirements:
Maintain ≤0.3mm/m alignment tolerance during mounting. Apply lithium soap-based grease
to locking wedge monthly. Avoid side loads exceeding 10% of maximum thrust. Locking
mechanism activates only when pressure drops below 0.15 MPa - verify system decay rate
during safety validation.
| Property | Property Value |
|---|---|
| sku | SULB63X550 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 550mm |
| Lock Position | Rear Cover with Lock Type |
