Airtac SULB Lock Cylinder SULB63X75
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB63X75 Locking Cylinder Specifications
- Model: SULB63X75
- Type: Double-acting cylinder with mechanical lock
- Bore size: 63mm
- Stroke: 75mm
- Operating pressure: 0.05–0.8 MPa
- Locking force: ≥350N (at 0.5MPa)
- Mounting style: Basic type (MF1) / Front flange (MF2) optional
- Cushioning: Adjustable elastic cushion
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Lock mechanism: Spring-activated brake system
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 3.5kg ±5%
- Dimensions: 250mm(L) × 90mm(W) × 90mm(H)
- Port size: M14×1.5 (G1/8 adaptor included)
- Protection rating: IP54 (standard), IP67 optional
High-precision locking cylinder with fail-safe mechanical brake, designed for vertical load holding and emergency stop scenarios. Features dual-position locking capability through integrated wedge mechanism, maintaining position even during air pressure loss. Requires 5-40μm filtered lubricated air (ISO 8573-1 class 3).
- Elevator safety brakes in material handling systems
- Position retention in CNC tool changers
- Overhead conveyor emergency stops
- Press machine mid-stroke holding
- Solar panel tilt adjustment mechanisms
Installation criticals:
Lock engages automatically at stroke ends - ensure proper alignment with load direction.
Requires monthly lubrication (VG32 hydraulic oil recommended).
Do not exceed 0.8m/s piston speed during operation.
| Property | Property Value |
|---|---|
| sku | SULB63X75 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 75mm |
| Lock Position | Rear Cover with Lock Type |
