Airtac SULB Lock Cylinder SULB63X80
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB63X80 Rear Locking Cylinder Specifications
- Model: SULB63X80
- Type: Double-acting cylinder with mechanical locking
- Bore size: 63mm
- Stroke: 80mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable hydraulic buffer (both ends)
- Locking force: 1,960N (at 0.5MPa)
- Operation direction: Bidirectional locking (axial)
- Mounting style: Square flange (ISO 15552 standard)
- Port size: G1/8 (NPT1/8 optional)
- Temperature range: -20℃ to 80℃
- Body material: Aluminum alloy (anodized)
- Rod material: Chrome-plated steel
- Seal material: NBR + PU combination
- Weight: 3.8kg (without accessories)
- Dimensions: 258mm(L) × 80mm(W) × 80mm(H) (stroke extended)
- Lock release pressure: ≥0.15MPa
- Response time: ≤0.5s (locking engagement)
Industrial-grade locking cylinder featuring fail-safe position retention through mechanical wedges. The dual-piston design ensures zero drift under load when locked, with IP64 protection against particulate ingress. Requires 5-40μm filtered air with ISO VG32 lubricant (optional oil-free operation).
- Vertical lifting mechanisms in assembly lines
- Clamping fixtures for CNC machining centers
- Safety brakes in material handling systems
- Position holding in injection molding machines
- Precision alignment stages in optical equipment
Installation critical:
Must maintain ≤0.5mm perpendicularity between rod and load direction.
Perform lock engagement test at 50% pressure before full operation.
Relubricate every 5,000km of cumulative stroke movement.
| Property | Property Value |
|---|---|
| sku | SULB63X80 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 63mm |
| Stroke | 80 mm |
| Lock Position | Rear Cover with Lock Type |
