Airtac X-APP Fitting - Plug X-APP12
AirTAC X-APP12 Quick Connect Fitting - Tube Plug Specifications
- Model: X-APP12
- Type: Push-to-connect tube plug (one-touch fitting)
- Material: Brass with nickel plating
- Seal material: NBR (Nitrile Rubber)
- Thread standard: BSPP (Parallel Thread)
- Port size: G1/8 (R1/8)
- Tube compatibility: PU/Nylon tubes (OD 4mm or 6mm)
- Operating pressure: 0.3-1.5 MPa
- Temperature range: -5℃ to 60℃
- Installation torque: 1.5-2 Nm
- Weight: 8g ±0.5g
- Dimensions: 15mm(L) × 12mm(W) × 12mm(H)
- IP rating: IP40
- Vibration resistance: ≤10Hz @ 2mm amplitude
A maintenance-friendly pneumatic connector featuring tool-free tube insertion and extraction. The tapered collet design ensures secure tube retention while allowing single-hand operation. Zinc-nickel composite coating provides corrosion resistance in humid environments. Rated for 100,000+ insertion cycles with proper lubrication.
- Modular pneumatic circuit connections
- Mobile hydraulic test bench setups
- Robotic end-effector tool changers
- Food processing equipment air lines
- Semiconductor manufacturing gas delivery
Installation protocol:
Cut tube ends square (90°±2°) and deburr before insertion.
For first-time use, apply silicone-based lubricant (JIS K2220 compliant)
to tube OD. Engage with firm push until audible click confirms full seating.
| Property | Property Value |
|---|---|
| sku | X-APP12 |
