Airtac X-APP Fitting - Plug X-APP6
AirTAC X-APP6 Push-in Fitting Tube Plug Specifications
- Model: X-APP6
- Type: Straight thread tube plug (push-in fitting series)
- Material: Nickel-plated brass body
- Applicable Tube OD: 6mm (1/4") pneumatic tubing
- Thread Size: M5×0.8 internal thread
- Operating Pressure: 0-1.0 MPa (0-145 PSI)
- Temperature Range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 15g ±0.5g
- Dimensions: 18mm(L) × 12mm(Dia) × 8mm(Hex key size)
- Seal Material: NBR (Nitrile) O-ring
- Standards Compliance: ISO 8434-1/DIN 2353
- IP Rating: IP40 (dust protected)
Precision-engineered sealing plug for terminating unused ports in pneumatic systems. Features dual-stage sealing with primary metal-to-metal thread contact and secondary NBR seal. Anti-vibration design maintains airtight performance under mechanical stress. Compatible with ISO pneumatic tube networks.
- Blocking residual ports in modular valve manifolds
- Emergency line isolation in automated assembly lines
- Dust prevention in food packaging machinery
- Test point sealing during pneumatic system maintenance
- Robotic gripper pneumatic circuit customization
Installation guide:
Hand-tighten until resistance is felt, then apply 1/4 turn with wrench.
Maximum torque 1.2N·m. Apply pneumatic sealant on threads if used in
high-vibration environments. Replace O-ring every 5 years or 10,000 cycles.
| Property | Property Value |
|---|---|
| sku | X-APP6 |
