Airtac X-M 3-Pin Female Connector X-M123F2.9G02PVC
AirTAC X-M Series 3-Pin Female Connector X-M123F2.9G02PVC Technical Details
- Full Model: X-M123F2.9G02PVC
- Series: X-M Compact Circular Connector
- Contact Type: 3-pin female socket
- Housing Material: Glass-fiber reinforced PVC (UL94 V-0)
- Contact Material: Gold-plated brass (0.5μm thickness)
- Color Code: Gray (RAL 7035 equivalent)
- Voltage Rating: 250V AC/DC
- Current Rating: 5A per contact
- Wire Gauge: Compatible with 20-28 AWG
- Contact Resistance: ≤10mΩ initial
- Insulation Resistance: ≥100MΩ (500V DC)
- Dielectric Strength: 1500V AC for 1 minute
- Operating Temp: -25℃ to +85℃ (ambient)
- IP Rating: IP67 when mated
- Mating Cycles: ≥500 cycles
- Weight: 15g ±0.5g
- Dimensions: 23mm(L) × 12.5mm(W) × 8mm(H)
- Locking Mechanism: Push-pull bayonet coupling
High-density interconnect solution designed for control cabinet wiring and sensor/actuator connections. Features anti-vibration design with audible mating confirmation click. The color-coded polarization prevents mismating between similar connectors. Compatible with M12x1 male threaded connectors.
- PLC I/O module wiring in industrial automation
- Servo motor feedback cable termination
- Packaging machine sensor clusters
- Robotic arm tool changer interfaces
- Medical device control panel wiring
Installation guidance:
Use certified M12 crimping tools (e.g., RIDGID 2748) for terminal assembly.
Maintain 8-10mm wire stripping length and ensure full insertion of contacts
until positive lock engagement. Apply silicone grease (Dielectric Strength ≥15kV)
for harsh environment applications.
| Property | Property Value |
|---|---|
| sku | X-M123F2.9G02PVC |
