Airtac X-M 3-Pin Female Connector X-M123F3.3G02PVC
AirTAC X-M Series 3-Pin Female Connector X-M123F3.3G02PVC Technical Details
- Model: X-M123F3.3G02PVC
- Type: 3-pin female socket connector (pre-wired)
- Contact arrangement: 3 positions in-line
- Wire gauge: 3.3mm² (AWG 12 compatible)
- Housing material: UV-resistant PVC (gray RAL 7035)
- Contact material: Gold-plated brass (3μm thickness)
- Voltage rating: 300V AC/DC max
- Current rating: 16A continuous
- Temperature range: -40℃ to +105℃
- Contact resistance: ≤5mΩ
- Insulation resistance: ≥100MΩ (500V DC)
- Dielectric strength: 1500V AC/min
- Mating cycles: ≥500 times
- Protection class: IP67 (mated)
- Cable length: 200±10mm (standard pre-attached)
- Cable jacket: Oil-resistant PVC (OD 8.0mm)
- Weight: 18g (connector only) / 45g (with cable)
- Dimensions: 32mm(L) × 15mm(W) × 10mm(H)
Industrial-grade connector featuring a secure push-pull locking mechanism with audible click engagement. The polarized design prevents mismating and includes silicone O-rings for environmental sealing. Pre-crimped with 3-color coded wires (Brown/Blue/Black-Yellow) for phase/neutral/ground identification.
- Sensor and actuator wiring in pneumatic systems
- Modular connections for I/O modules on PLC racks
- Servo motor power/signal interfaces
- Material handling equipment quick-disconnect points
- Robotic arm tool changer electrical interfaces
Installation note:
Ensure full insertion until the lock tab snaps into position. For IP67 rating,
verify the mating connector's sealing surface is clean and lubricant-free.
Maximum torque during panel mounting: 0.8N·m.
- X-M123M3.3G02PVC (Male counterpart)
- Compatible with IEC 61076-2-101 standard housings
| Property | Property Value |
|---|---|
| sku | X-M123F3.3G02PVC |
