Airtac X-M 3-Pin Female Connector X-M123F4.0B02PVC
$10.92
Regular price
$18.42
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-M123F4.0B02PVC
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-M Series 3-Pin Female Connector X-M123F4.0B02PVC Technical Details
- Full model designation: X-M123F4.0B02PVC
- Contact configuration: 3-pin female (socket)
- Contact material: Phosphor bronze with gold plating (0.8μm thickness)
- Current rating: 5A AC/DC per contact
- Voltage rating: 250V AC/DC
- Wire compatibility: 20-24 AWG (0.5-1.3mm²)
- Pin diameter: 4.0mm ±0.05mm
- Housing material: UL94 V-0 PVC (black)
- Temperature range: -25℃ to +105℃
- Contact resistance: ≤10mΩ initial
- Insulation resistance: ≥100MΩ (500VDC)
- Dielectric strength: 1500V AC for 1 minute
- IP rating: IP67 when mated
- Mating cycles: ≥500 insertions
- Weight: 12.5g ±0.3g
- Dimensions: 23.8mm(L) × 18.6mm(W) × 14.2mm(H)
- Locking mechanism: Dual-stage click lock with anti-snag design
- Certifications: CE, RoHS, REACH compliant
Industrial-grade circular connector featuring oil-resistant PVC housing and precision-machined contacts. The patented B02 series locking system prevents accidental disconnection in high-vibration environments. Includes integrated O-ring (NBR material) for environmental sealing.
Application Scenarios:
- Robotic arm signal/power interfaces
- Conveyor system sensor connections
- CNC machine tool I/O modules
- Outdoor LED lighting arrays
- Food processing equipment (washdown areas)
Installation guidance:
Use proper crimping tool (AMP/TE equivalent) for terminal attachment.
Ensure complete O-ring seating before mating. Maximum wire bend radius
4× cable diameter. Torque limit: 0.5-0.8N·m during panel mounting.
| Property | Property Value |
|---|---|
| sku | X-M123F4.0B02PVC |
