Airtac X-M 3-Pin Female Connector X-M123F4.0G02PVC
AirTAC X-M Series 3-Pin Female Connector X-M123F4.0G02PVC Technical Details
- Full Model: X-M123F4.0G02PVC
- Series: X-M Standard Wire-to-Board Series
- Pins: 3-position female socket
- Pitch: 4.0mm (center-to-center spacing)
- Contact Material: Phosphor bronze (gold-plated 0.8μm)
- Insulator Material: UL94V-0 rated PBT
- Wire Gauge: Compatible with 26-22 AWG (0.3-0.5mm²)
- Rated Voltage: 300V AC/DC
- Current Rating: 5A per contact
- Contact Resistance: ≤20mΩ initial
- Insulation Resistance: ≥1000MΩ (500VDC)
- Dielectric Strength: 1500V AC/minute
- Operating Temp: -25℃ to +105℃
- Housing Color: Gray PVC jacket (RAL 7035 equivalent)
- Mating Cycles: ≥50 insertions
- Weight: 3.8g ±0.2g
- Dimensions: 15.2mm(L) × 10.6mm(W) × 8.4mm(H)
- Safety Certifications: RoHS compliant, REACH SVHC-free
High-density industrial connector featuring anti-vibration design with dual-lock secondary retention. The gold-plated contacts ensure stable signal transmission in humid environments (up to 85% RH non-condensing). Prevents misalignment with polarized housing and includes strain relief wings for secure cable management.
- Servo motor encoder wiring in CNC machinery
- Modular PLC I/O signal connections
- Sensor cluster interfaces for automated assembly lines
- Power distribution in 3D printer control boards
- Medical device control panel interconnects
Installation guidance:
Use compatible XM-09 crimping tool (AIRTAC PN: CT-4567) for terminal assembly.
Maintain 12mm minimum bend radius during cable routing. Avoid repeated mating cycles
beyond specification to prevent contact wear.
Not recommended for:
High-voltage power transmission (>300V) or applications with continuous lateral stress.
Use strain relief clamps when exposed to vibration >5G acceleration.
| Property | Property Value |
|---|---|
| sku | X-M123F4.0G02PVC |
