Airtac X-M 3-Pin Female Connector X-M123F4.0G03PVC
AirTAC X-M Series 3-Pin Female Connector X-M123F4.0G03PVC Technical Details
- Full Model Code: X-M123F4.0G03PVC
- Series: X-M Compact Circular Connector Family
- Contact Configuration: 3-pin female (socket)
- Pin Diameter: 4.0mm ±0.05mm gold-plated contacts
- Wire Gauge Compatibility: 20-24 AWG
- Rated Voltage: 300V AC/DC
- Current Capacity: 5A per contact (3A continuous)
- Insulation Resistance: ≥100MΩ (500VDC)
- Dielectric Strength: 1500V AC for 1 minute
- Housing Material: UV-resistant PVC (UL94 V-0)
- Contact Material: Brass with 0.8μm nickel underplate + 0.2μm gold flash
- IP Rating: IP67 when mated
- Operating Temperature: -25℃ to +85℃
- Mating Cycles: ≥5000 insertions
- Weight: 12.5g ±0.3g (excluding cable)
- Dimensions: 23.8mm(D) × 18.4mm(H) × 16.2mm(W)
- Locking Mechanism: Push-pull quick release with tactile click
Industrial-grade circular connector featuring gold-plated contacts for reliable signal transmission in high-vibration environments. The bayonet-style coupling ensures secure connections with single-handed operation, while the color-coded alignment key prevents mismating. Compatible with standard M12x1 threaded connectors.
- Servo motor feedback cable assemblies
- PLC I/O module interconnections
- Robotic end effector power/signal integration
- Sensor networks in food processing equipment
- Mobile hydraulic control systems
Installation guidance:
Use proper crimping tool (AMP 91522-1 recommended) for contact termination.
Maintain 15mm cable strain relief and avoid sharp bends (minimum 4x cable diameter radius).
| Property | Property Value |
|---|---|
| sku | X-M123F4.0G03PVC |
