Airtac X-M 3-Pin Female Connector X-M123F4.4B03PVC
AirTAC X-M Series 3-Pin Female Connector X-M123F4.4B03PVC Technical Details
- Full Model Code: X-M123F4.4B03PVC
- Connector Type: 3-pin female (socket)
- Contact Configuration: Straight PCB mount
- Wire Gauge Compatibility: 22-24 AWG
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: ≤10mΩ (initial)
- Insulation Resistance: ≥1000MΩ (500V DC)
- Dielectric Strength: 1500V AC/min
- Pin Spacing: 4.4mm pitch (center-to-center)
- Contact Material: Phosphor bronze with gold plating (0.8μm)
- Housing Material: UL94 V-0 PVC
- Operating Temperature: -25℃ to +105℃
- Mating Cycles: ≥50 times
- Protection Class: IP67 (when mated)
- Weight: 2.8g ±0.2g
- Dimensions: 15.2mm(L) × 10.6mm(W) × 8.3mm(H)
Compact 3-pin connector with anti-reverse design, featuring gold-plated contacts for stable signal transmission in vibration-prone environments. The double-lock structure ensures secure wire retention, while the polarized housing prevents incorrect mating. Compatible with 1.5mm² crimp terminals.
- Servo motor encoder connections
- PLC I/O module wiring
- Industrial sensor interfaces (photoelectric/ proximity sensors)
- Robotic arm control signal transmission
- CNC machine tool limit switch circuits
Installation Guidelines:
Use AMP-20046 crimping tool for terminal attachment. Maintain minimum 5x wire diameter bend radius.
For IP67 sealing, ensure mating connector (X-M123M4.4B03PVC) is properly engaged with audible click.
| Property | Property Value |
|---|---|
| sku | X-M123F4.4B03PVC |
