Airtac X-M 3-Pin Female Connector X-M83F2.9B02PVC
$8.13
Regular price
$15.63
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-M83F2.9B02PVC
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-M Series 3-Pin Female Connector X-M83F2.9B02PVC Technical Specifications
- Model Code: X-M83F2.9B02PVC
- Series: X-M Compact Industrial Connector Series
- Contact Configuration: 3-pin female (socket)
- Contact Material: Gold-plated copper alloy (0.6μm thickness)
- Contact Resistance: ≤30mΩ (initial)
- Rated Current: 5A per contact
- Rated Voltage: 250V AC/DC
- Wire Gauge Compatibility: 20-28 AWG
- Insulation Resistance: ≥100MΩ (500V DC)
- Dielectric Strength: 1500V AC/min (contact to shell)
- Housing Material: UL94V-0 rated PVC
- Operating Temperature: -25℃ to +85℃
- Mating Cycles: ≥1,000 cycles
- Ingress Protection: IP67 (mated), IP2X (unmated)
- Cable Entry: 2.9mm diameter (for Ø2.9mm cable gland)
- Locking Mechanism: Push-pull quick connect with audible click
- Weight: 12g ±0.5g (connector only)
- Dimensions: 19.5mm(L) × 11.5mm(W) × 8mm(H)
- Color Coding: Black housing with white position markers
- Compliance: RoHS 2.0, REACH, UL1977 recognized
High-density electrical connector designed for signal transmission in harsh environments. Features anti-vibration design with double-lock contacts and strain relief. The 360° shielded design minimizes EMI interference, with a 2.5mm creepage distance between contacts.
Typical Applications:
- Industrial robot end-effector wiring systems
- CNC machine tool sensor connections
- Packaging equipment photoelectric switches
- Automated guided vehicle (AGV) power/signal interfaces
- PLC I/O module field wiring
- Medical device control panel interconnects
Installation guidelines:
Use proper crimping tool (JST YRC-2801 recommended) for terminal assembly.
Maintain 50mm minimum bend radius for cables. Apply silicone grease (NSH-3AS)
when used in high humidity environments. Avoid mating under load conditions.
Packaging: Bulk packed in anti-static bags, 100pcs/box.
Terminal pins sold separately (P/N: X-M83T-2.3B01)
| Property | Property Value |
|---|---|
| sku | X-M83F2.9B02PVC |
