Airtac X-M 3-Pin Female Connector X-M83F2.9B03PVC
AirTAC X-M Series 3-Pin Female Header Connector X-M83F2.9B03PVC Technical Details
- Full Model: X-M83F2.9B03PVC
- Series: X-M Compact Industrial Series
- Pin Configuration: 3-pin female (socket)
- Pin Diameter: 2.9mm ±0.02mm (gold-plated brass)
- Housing Material: UL94 V-0 PVC (black)
- Contact Resistance: ≤10mΩ
- Rated Voltage: 300V AC/DC
- Current Capacity: 5A max per contact
- Temperature Range: -25℃ to +105℃
- Insulation Resistance: ≥1000MΩ (500V DC)
- Dielectric Strength: 1500V AC/min
- Wire Gauge Compatibility: 20-24 AWG
- Mating Cycles: ≥50 times
- Weight: 3.8g ±0.2g
- Dimensions: 21.5mm(L) × 10.2mm(W) × 8.7mm(H)
Robust polarized connector with audible mating click, featuring anti-wicking design to prevent fluid ingress. The 2.9mm pins employ a dual-spring contact system for vibration resistance (tested to 10-55Hz). Includes color-coded alignment ribs and IP67-rated sealing when mated with corresponding plug.
- PLC I/O module wiring in factory automation
- Servo motor encoder connections
- Industrial sensor networks (proximity switches, photoelectric sensors)
- CNC machine control panel interconnects
- Robotic arm power/signal transmission
Installation guidelines:
Use proper crimping tool (JST YRS-1802 recommended) with 2.5-3.5mm² stripping length.
Avoid simultaneous mating of multiple connectors - stagger by 0.5mm offset during panel layout.
| Property | Property Value |
|---|---|
| sku | X-M83F2.9B03PVC |
