Airtac X-M 3-Pin Female Connector X-M83F2.9G02PVC
AirTAC X-M Series 3-Pin Female Connector X-M83F2.9G02PVC Technical Details
- Model: X-M83F2.9G02PVC
- Series: X-M Compact Wire-to-Board Series
- Contact type: Female socket (3 circuits)
- Pin pitch: 2.9mm horizontal spacing
- Terminal material: Copper alloy with gold plating (0.8μm)
- Contact resistance: ≤20mΩ initial
- Insulation resistance: ≥1000MΩ (500VDC)
- Withstand voltage: 600V AC/min
- Current rating: 3A per contact
- Wire gauge compatibility: 28-22 AWG
- Housing material: UL94 V-0 PA66 (black)
- Operating temperature: -25℃ to +85℃
- Mating cycles: ≥50 times
- Weight: 1.7±0.2g (connector only)
- Dimensions: 15.2mm(L) × 7.8mm(W) × 5.3mm(H)
- Certification: RoHS compliant
High-density miniature connector featuring precision-molded housing and anti-vibration locking design. The gold-plated contacts ensure stable signal transmission in harsh environments. Compatible with automated crimping processes and manual assembly. Includes polarization key to prevent mismating.
- Sensor wiring in pneumatic valve manifolds
- Servo motor feedback cable connections
- PLC I/O module interfacing
- Robotic end effector control circuits
- Packaging machine safety interlock systems
Installation note:
Use proper crimping tool (JST YRS-1800 recommended) with 0.3-0.5N·m torque.
Avoid repeated mating/unmating cycles beyond specification. For vertical installations,
secure cable with strain relief within 50mm of connector.
- Header: X-M83T2.9G02 (PCB male header)
- Seal option: X-M83S (IP67 sealing plug available)
- Cable clamp: X-M83C (strain relief accessory)
| Property | Property Value |
|---|---|
| sku | X-M83F2.9G02PVC |
