Airtac X-M 3-Pin Female Connector X-M83F2.9G03PVC
$8.34
Regular price
$15.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-M83F2.9G03PVC
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-M Series 3-Pin Female Connector X-M83F2.9G03PVC Technical Details
- Model: X-M83F2.9G03PVC
- Type: 3-pin female quick-disconnect connector
- Contact Configuration: 3 circuits (3C)
- Pin Diameter: 2.9mm ±0.02mm
- Housing Material: High-strength PVC (UL94 V-0 rated)
- Contact Material: Phosphor bronze with gold plating (0.8μm)
- Rated Current: 5A per contact @ 250V AC/DC
- Insulation Resistance: ≥100MΩ (500V DC)
- Withstand Voltage: 1500V AC/min
- Operating Temperature: -25℃ to +85℃
- Wire Compatibility: 20-24 AWG
- Mating Cycles: ≥500 insertions
- Protection Rating: IP67 (mated), IP2X (unmated)
- Weight: 12g ±0.5g
- Dimensions: 29mm(L) × 18mm(W) × 15mm(H)
- Flammability Rating: UL94 HB
Robust circular connector with positive-lock mechanism designed for industrial control systems. Features gold-plated contacts for reliable signal transmission and anti-vibration design with audible mating confirmation. Compatible with standard 2.9mm male pins.
Common Applications:
- PLC I/O module wiring in factory automation
- Sensor cluster connections on robotic arms
- Power supply interfaces for pneumatic valves
- Motor encoder cable termination
- HMI panel peripheral connections
Installation guidance:
Use ratchet crimping tool (JST YRC-1840 recommended) for terminal attachment.
Ensure full insertion until hearing "click" sound. Apply silicone grease (NSF H1 grade)
when used in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | X-M83F2.9G03PVC |
