Airtac X-M 3-Pin Female Connector X-M83F2.9G05PVC
AirTAC X-M Series 3-Pin Female Connector X-M83F2.9G05PVC Technical Details
- Full Model: X-M83F2.9G05PVC
- Series: X-M Compact Interconnect System
- Contact Type: 3-pin female socket (gold-plated brass)
- Pin Diameter: 2.9mm ±0.02mm precision tolerance
- Housing Material: UL94 V-0 PVC (black)
- Voltage Rating: 250V AC/DC max
- Current Capacity: 5A continuous / 10A peak
- Contact Resistance: ≤10mΩ initial
- Insulation Resistance: ≥100MΩ (500V DC)
- Dielectric Strength: 1500V AC/min
- Operating Temp: -25℃ to +85℃ (no icing)
- Mating Cycles: ≥500 insertions
- Wire Gauge: Compatible with 22-24 AWG
- Cable Length: Standard 500mm (customizable)
- Protection Class: IP67 when mated
- Weight: 28g ±2g (connector only)
- Dimensions: 32mm(L) × 18mm(W) × 12.5mm(H)
- Locking Mechanism: Push-pull quick connect
- Certifications: RoHS, REACH compliant
High-density miniature connector featuring oil-resistant PVC housing and military-grade contact plating. Engineered for vibration-prone environments with self-cleaning contact design. Includes strain relief and polarization slots to prevent mismating. Compatible with standard X-M series headers.
- Servo motor feedback cable assemblies
- PLC I/O module interconnections
- Robotic end effector signal transmission
- CNC machine sensor wiring
- Food processing equipment (washdown environments)
- Battery management system (BMS) connections
Installation guidance:
Use proper crimping tool (AMP 1437274-1 recommended) for terminal assembly.
Maintain minimum 50mm bend radius for cables. Apply dielectric grease in
high-humidity environments. Mating force: 2-15N maximum.
| Property | Property Value |
|---|---|
| sku | X-M83F2.9G05PVC |
