Airtac X-M 3-Pin Female Connector X-M83F3.3G02PVC
AirTAC X-M Series 3-Pin Female Connector X-M83F3.3G02PVC Technical Details
- Model: X-M83F3.3G02PVC
- Type: 3-pin female quick-disconnect connector (panel mount)
- Contact configuration: 3 positions (1.5mm pitch)
- Pin diameter: 3.3mm ±0.05 (gold-plated brass contacts)
- Rated voltage: 24V DC (max 50V)
- Current capacity: 5A per pin (UL/EN certified)
- Contact resistance: ≤0.1Ω (initial)
- Insulation resistance: ≥100MΩ (500V DC)
- Housing material: UV-resistant PVC (UL94V-0 rated)
- Wire compatibility: 22-24 AWG (0.2-0.5mm²)
- Operating temperature: -25℃ to +85℃
- IP rating: IP67 (mated), IP40 (unmated)
- Mating cycles: ≥5,000 cycles
- Cable length: 300mm ±10% (standard PVC jacket)
- Weight: 24.5g ±0.3g (excluding cable)
- Dimensions: 28.5mm(L) × 15.2mm(W) × 9.8mm(H)
High-density signal connector with corrosion-resistant gold contacts, designed for vibration-prone environments. Features positive-lock tab mechanism and color-coded terminals (red/blue/black) for error-proof wiring. Compatible with X-M8 series male plugs using screw-lock coupling system.
- Sensor wiring in CNC machinery (proximity/photo sensors)
- Modular control panel interconnections
- AGV (Automated Guided Vehicle) power/signal transmission
- Industrial robot end effector connections
- PLC I/O cabinet wiring systems
Installation guidance:
Use proper crimping tool (recommended: YD-238H) for terminal attachment.
Maintain 15mm straight cable section before bend radius.
Apply dielectric grease (Molykote GN) in high-humidity environments.
| Property | Property Value |
|---|---|
| sku | X-M83F3.3G02PVC |
