Airtac X-M 3-Pin Female Connector X-M83F3.3G03PVC
AirTAC X-M Series 3-Pin Female Header Connector X-M83F3.3G03PVC Technical Details
- Model: X-M83F3.3G03PVC
- Series: X-M Compact Header Series
- Type: 3-pin female connector (vertical mount)
- Contact Material: Gold-plated copper alloy (3μm thickness)
- Insulator Material: UL94V-0 PVC (black)
- Current Rating: 5A AC/DC
- Voltage Rating: 250V AC/DC
- Wire Gauge Compatibility: AWG20-28 (0.5-1.0mm²)
- Pitch: 3.3mm (0.13") horizontal spacing
- Contact Resistance: ≤20mΩ initial
- Withstand Voltage: 1500V AC/min
- Mating Cycles: ≥50 cycles
- Operating Temp: -25℃ to +85℃
- Weight: 12g ±0.5g
- Dimensions: 25.4mm(L) × 10.2mm(W) × 8.6mm(H)
- Certification: RoHS compliant, UL1977 recognized
High-density signal connector with anti-mismatch keying design, featuring corrosion-resistant gold plating for stable low-voltage signal transmission. The polarized housing prevents reverse mating, with integrated locking tabs for secure PCB attachment. Compatible with 1.6-2.4mm thick PCBs.
- PLC I/O module wiring interfaces
- Sensor-to-controller signal links in automation systems
- Pneumatic valve manifold electrical connections
- CNC machine control panel assemblies
- Robotic arm servo motor feedback circuits
Installation guidelines:
Apply 2-3N insertion force during mating. For vertical PCB mounting,
reinforce solder joints with additional through-hole plating.
Maintain 5mm clearance from adjacent high-voltage components.
Avoid using in continuous high-vibration
environments without strain relief. Not recommended for
immersion or pressurized washdown applications.
| Property | Property Value |
|---|---|
| sku | X-M83F3.3G03PVC |
