Airtac X-M 3-Pin Female Connector X-M83F4.0B02PVC
AirTAC X-M Series 3-Pin Female Connector X-M83F4.0B02PVC Technical Details
- Model: X-M83F4.0B02PVC
- Type: 3-pin female quick-disconnect connector
- Wire gauge compatibility: 22-28 AWG
- Contact pins: 3 (gold-plated phosphor bronze)
- Insulation material: UL94 V-0 PVC
- Rated voltage: 300V AC/DC
- Current rating: 5A per contact
- Withstand voltage: 1500V AC/minute
- Temperature range: -25℃ to +85℃
- Contact resistance: ≤10mΩ
- Insulation resistance: ≥100MΩ (500V DC)
- Mating cycles: ≥50 times
- Wire length: 300mm standard
- Cable jacket: Oil-resistant PVC (OD 4.0±0.1mm)
- Protection rating: IP67 (mated)
- Weight: 12g ±0.5g
- Dimensions: 32mm(L) × 15mm(W) × 8.5mm(H)
Dust-proof and vibration-resistant electrical connector featuring a positive-lock mechanism with audible click engagement. The angled strain relief prevents cable bending damage, while the color-coded housing (standard black) enables quick visual identification in multi-connection setups. Compatible with X-M8 series male headers.
- Servo motor feedback cable connections
- PLC I/O module wiring harnesses
- Robotic arm sensor interfaces
- Packaging machine safety circuit links
- AGV charging port connectors
Installation guidance:
Use crimping tool CT-258 for terminal assembly. Maintain 50mm minimum
unbent cable length from connector rear. For IP67 rating, ensure complete
insertion until locking tab fully engages with male counterpart.
| Property | Property Value |
|---|---|
| sku | X-M83F4.0B02PVC |
