Airtac X-M 3-Pin Female Connector X-M83F4.0B03PVC
$8.90
Regular price
$16.40
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-M83F4.0B03PVC
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-M Series 3-Pin Female Connector X-M83F4.0B03PVC Specifications
- Model: X-M83F4.0B03PVC
- Type: Sealed 3-pin female quick connector
- Contact configuration: 3 sockets (16-22 AWG compatible)
- Wire entry diameter: Ø4.0mm (accommodates 3.5-4.5mm cables)
- Rated voltage: 300V AC/DC
- Current rating: 5A per contact
- Contact resistance: ≤10mΩ
- Insulation resistance: ≥100MΩ (500V DC)
- Housing material: UL94 V-0 PVC (black)
- Contact material: Phosphor bronze with gold plating (0.8μm)
- Sealing rating: IP67 (mated), IP40 (unmated)
- Temperature range: -25℃ to +85℃
- Mating cycles: ≥500 insertions
- Weight: 12.5g ±0.3g
- Dimensions: 23.8mm(L) × 18.6mm(W) × 14.2mm(H)
- Locking mechanism: Dual-stage click-lock with dust cover
- Compliance: RoHS 2.0, REACH
Industrial-grade moisture-resistant connector featuring anti-vibration design with 360° shielding. Prevents reverse mating through asymmetrical keying. Integrated strain relief accommodates Ø3.5-4.5mm cables. Compatible with M8x1 male threaded connectors.
Typical Applications:
- Sensor wiring in CNC machine tooling
- Robotic arm power/signal transmission
- Conveyor system proximity switches
- Packaging machine I/O connections
- Outdoor LED lighting arrays
Installation note:
Use proper crimping tool (AWG-specific dies recommended). Maintain 8mm minimum
cable bend radius. Apply silicone grease on seals for harsh environments.
Torque limit: 0.6-0.8Nm during panel mounting.
| Property | Property Value |
|---|---|
| sku | X-M83F4.0B03PVC |
