Airtac X-M 3-Pin Female Connector X-M83F4.0B05PVC
AirTAC X-M Series 3-Pin Female Connector X-M83F4.0B05PVC Technical Details
- Full Model Code: X-M83F4.0B05PVC
- Series: X-M Compact Industrial Connector Series
- Type: Female Socket Connector (Panel Mount)
- Contact Configuration: 3-pin (Triple Circuit)
- Wire Gauge Compatibility: 4.0mm² (AWG 12)
- Contact Material: Phosphor Bronze with Gold Flash (3μm)
- Insulator Material: Heat-resistant PVC (UL94 V-0 rated)
- Voltage Rating: 250V AC/DC
- Current Capacity: 5A per contact
- Operating Temp Range: -25℃ to +85℃
- Contact Resistance: ≤10mΩ (initial)
- Insulation Resistance: ≥100MΩ (500V DC)
- Dielectric Strength: 1500V AC/min
- IP Rating: IP67 (mated), IP20 (unmated)
- Mating Cycles: ≥5,000 insertions
- Weight: 15.2g ±0.3g
- Dimensions: 20.5mm(L) × 15.8mm(W) × 10.3mm(H)
- Locking Mechanism: Push-pull bayonet lock with tactile click
- Wire Termination: Screw-clamp (torque 0.4Nm)
Industrial-grade circular connector featuring anti-vibration design with stainless steel spring-loaded contacts. Sealed against dust ingress and temporary immersion (IP67). The color-coded PVC housing (B05=blue) enables quick visual identification in control panels. Includes integrated strain relief and finger grips for tool-free mating.
- Servo motor power/signal hybrid connections
- CNC machine tool I/O interfaces
- Automated guided vehicle (AGV) charging ports
- Industrial robot end effector wiring
- PLC control cabinet field wiring
- Packaging machinery sensor clusters
Installation Guidelines:
Use torque-limiting driver for terminal screws. Apply dielectric grease (VDE 0611 compliant)
in high-humidity environments. Maintain minimum 5mm clearance between adjacent connectors
for heat dissipation. Test mating alignment with dummy plug before final assembly.
| Property | Property Value |
|---|---|
| sku | X-M83F4.0B05PVC |
