Airtac X-M 3-Pin Female Connector X-M83F4.0B10PVC
$14.64
Regular price
$22.14
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-M83F4.0B10PVC
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-M Series 3-Pin Female Connector X-M83F4.0B10PVC Technical Details
- Full Model: X-M83F4.0B10PVC
- Series: X-M Compact Connector Series
- Terminal Type: 3-pin female socket (receptacle)
- Contact Pitch: 4.0mm ±0.1mm horizontal spacing
- Wire Gauge: Accepts 22-26 AWG (0.3-0.8mm²)
- Housing Material: UL94 V-0 PVC (black)
- Contact Material: Phosphor bronze with gold plating (3μm)
- Current Rating: 5A AC/DC max per contact
- Voltage Rating: 250V AC/DC
- Insulation Resistance: ≥100MΩ (500VDC)
- Withstand Voltage: 1500V AC/min
- Operating Temp: -25℃ to +85℃ (no icing)
- IP Rating: IP67 when mated
- Weight: 23g ±1g (excluding wires)
- Dimensions: 32.5mm(L) × 12.8mm(W) × 9.7mm(H)
Vibration-resistant connector featuring color-coded slots (red/blue/yellow) for error-proof assembly. The friction-lock design requires 6.5N minimum mating force, with dual-polarization keys preventing incorrect mating. Compatible with standard 4.0mm male headers.
Common Applications:
- Servo motor encoder wiring in CNC machines
- PLC I/O module signal connections
- Temperature sensor interfaces in food processing equipment
- Robotic arm joint position feedback systems
- UV printer head control cable assemblies
Installation guidance:
Use certified crimp tool CT-456 for terminal assembly.
Maximum wire strip length: 7.5mm. Apply silicone grease (ASG-32 recommended)
when used in high-humidity environments. Avoid repeated mating cycles beyond 50 times.
| Property | Property Value |
|---|---|
| sku | X-M83F4.0B10PVC |
