Airtac X-M 3-Pin Female Connector X-M83F4.0G02PVC
AirTAC X-M Series 3-Pin Female Connector X-M83F4.0G02PVC Technical Details
- Model: X-M83F4.0G02PVC
- Type: 3-pin female connector (socket)
- Contact arrangement: 3 circuits (1NC+1NO+1COM)
- Wire size compatibility: 28-22 AWG (0.08-0.5mm²)
- Rated voltage: 250V AC/DC
- Current rating: 5A max
- Contact resistance: ≤50mΩ initial
- Insulation resistance: ≥100MΩ (500V DC)
- Dielectric strength: 1500V AC/min
- Housing material: PBT + 30% glass fiber (UL94 V-0)
- Contact material: Gold-plated brass
- Operating temperature: -25℃ to +105℃
- Protection class: IP67 (mated)
- Mating cycles: ≥100 times
- Weight: 18g ±0.5g
- Dimensions: 30mm(L) × 18mm(W) × 12.5mm(H)
Sealed multi-circuit connector featuring color-coded slots (Red/Blue/Yellow) for error-proof wiring. The gold-plated contacts ensure stable signal transmission in high-vibration environments. Includes integrated PVC cable gland (4.0mm diameter) with strain relief. Compatible with XM8 series male headers.
- Sensor wiring in CNC machinery
- Modular pneumatic valve island connections
- AGV (Automated Guided Vehicle) control systems
- Packaging line I/O signal transmission
- Robotic end effector power/signal integration
Installation note:
Use 2.5-3.5N·m torque for screw terminals. Apply dielectric grease
in high-humidity environments. For IP67 integrity, ensure O-ring
is lubricated before mating and cable gland is fully tightened.
| Property | Property Value |
|---|---|
| sku | X-M83F4.0G02PVC |
