Airtac X-M 3-Pin Female Connector X-M83F4.0G03PVC
$8.34
Regular price
$15.84
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-M83F4.0G03PVC
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-M Series 3-Pin Female Connector X-M83F4.0G03PVC Technical Details
- Full Model Code: X-M83F4.0G03PVC
- Type: 3-pin female socket connector (straight type)
- Contact Material: Gold-plated brass (3μm thickness)
- Wire Gauge: 4.0mm² (AWG 11 compatible)
- Thread Specification: G3/8" (BSPP) straight thread
- Rated Voltage: 250V AC/DC
- Current Rating: 16A continuous load
- Insulation Resistance: ≥100MΩ (500V DC)
- Dielectric Strength: 1500V AC/min
- Housing Material: UL94 V-0 rated nylon
- Seal Type: Dual silicone O-rings (ø14mm and ø18mm)
- Protection Class: IP67 when mated
- Temperature Range: -25℃ to +105℃
- Weight: 28.5g ±0.5g
- Dimensions: 38mm(L) × 24mm(W) × 32mm(H)
- Cable Entry: M16×1.5 cable gland (PVC jacket compatible)
High-density industrial connector featuring twist-lock coupling mechanism with 120° rotation limit. The gold-plated contacts ensure stable signal transmission in vibration-prone environments. Anti-mismake design prevents incorrect mating sequence. Compatible with X-M83M series plugs.
Typical Installations:
- Servo motor power/signal hybrid connections
- Automated guided vehicle (AGV) charging interfaces
- PLC I/O module field wiring
- Robotic arm sensor clusters
- Outdoor LED lighting arrays
Mating procedure:
Align red alignment marks, insert until click sound heard,
then rotate clockwise 45° for full lock. Disconnect only after
releasing safety latch.
Avoid repeated mating cycles
(>5,000 times) in high humidity (>85% RH) environments.
Recommended torque: 1.2-1.5N·m during installation.
| Property | Property Value |
|---|---|
| sku | X-M83F4.0G03PVC |
