Airtac X-M 3-Pin Female Connector X-M83F4.0G05PVC
AirTAC X-M Series 3-Pin Female Connector X-M83F4.0G05PVC Technical Details
- Model: X-M83F4.0G05PVC
- Type: Panel-mounted 3-pin female connector
- Pin configuration: 3 circular pins (female sockets)
- Pin spacing: 4.0mm pitch
- Wire gauge compatibility: AWG 22-24 (0.3-0.5mm²)
- Contact material: Phosphor bronze with gold plating (3μm)
- Insulation material: UL94 V-0 PVC
- Wire color coding: Black (common), Red (+), Blue (-)
- Current rating: 5A AC/DC max
- Voltage rating: 250V AC/DC
- Insulation resistance: ≥100MΩ (500VDC)
- Dielectric strength: 1500V AC/min
- Operating temperature: -25℃ to +85℃
- Weight: 12.5g ±0.3g (excluding wires)
- Dimensions: 23.8mm(L) × 15.2mm(W) × 9.6mm(H)
- Mounting hole size: Ø4.3mm (panel cutout)
- IP rating: IP40 (IP67 when mated with male connector)
Robust miniature connector designed for industrial control systems requiring space-efficient signal/power transmission. Features anti-vibration pin locking, polarized mating design, and color-coded wiring for error-proof installation. The gold-plated contacts ensure stable conductivity in humid environments (RH ≤95%). Compatible with standard X-M series male headers.
- PLC I/O module wiring in factory automation
- Servo motor feedback cable connections
- Sensor power/signal transmission in packaging machinery
- Medical equipment control panel interfaces
- Robotic arm joint wiring harnesses
Installation guidance:
Use proper crimping tool (AMP 917646-1 recommended) for terminal attachment.
Maximum wire bend radius: 4× cable diameter. Avoid repeated mating cycles (>500 times).
| Property | Property Value |
|---|---|
| sku | X-M83F4.0G05PVC |
