Airtac X-M 3-Pin Female Connector X-M83FL3.3B02PVC
$8.13
Regular price
$15.63
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-M83FL3.3B02PVC
Product type:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-M Series 3-Pin Female Connector X-M83FL3.3B02PVC Technical Details
- Full Model Number: X-M83FL3.3B02PVC
- Series: X-M Standard Locking Type
- Contact Type: Female socket (3 circuits)
- Contact Material: Phosphor bronze (gold-plated 0.8μm)
- Insulator Material: UL94V-0 PVC
- Contact Resistance: ≤10mΩ (initial)
- Withstand Voltage: 1500V AC/min
- Rated Current: 5A per contact
- Wire Gauge Compatibility: 28-22 AWG (0.08-0.35mm²)
- Mating Cycles: ≥50 times
- Operating Temp: -25℃ to +85℃ (no icing)
- Protection Class: IP67 (mated state)
- Weight: 8.2±0.5g
- Dimensions: 23.5mm(L) × 13.8mm(W) × 18.6mm(H)
- Locking Mechanism: Side-latch with audible click
- Pitch: 3.3mm between contacts
High-density industrial connector featuring oil-resistant PVC housing and secure slide-lock design. The gold-plated contacts ensure stable signal transmission in vibration-prone environments. Sealed against dust ingress and low-pressure water jets (JIS C 0920 protection standard).
Common Implementations:
- Servo motor encoder cable termination
- PLC I/O module wiring in automated assembly lines
- Sensor interconnect in food processing machinery
- Robotic arm control signal transmission
- Conveyor system photoelectric switch integration
Installation guidance:
Use compatible crimping tool (e.g., JST YRS-1000) with 1.5-2.5mm² stripper.
Maintain 10mm wire tail length after insulation displacement.
Avoid repeated mating/unmating beyond rated cycles to prevent latch wear.
Mating Parts:
Pairs with X-M83ML3.3B02PVC male header.
Cross-compatible with JST XH series using adapter harness (not recommended for high-vibration apps).
| Property | Property Value |
|---|---|
| sku | X-M83FL3.3B02PVC |
